High Precision 30mm Metal Drilling Milling Machine
Item NO: MM-BF30 Vario



  • Product Name :      Ø 30mm Drilling Milling Machine
  • Trade Terms :         FOB, CFR, CIF
  • Payment Terms :    T/T, L/C
  • Loading Port :        SHANGHAI or YANGZHOU Sea Port
  • Packing Type :        Reinforced Wooden Case
  • Delivery Time :        Within 1--2 weeks
  • Delivery Type :        Transportation By Sea or By Air
  • Mini Order Quantity :  1 Unit
  • Brand Name :          OEM or MAXNOVO
  • Supply Ability :        More than 5000 units every year
  • Quotation Valid :     Within 15 days since quotation date
  • Safety Certificate :  CE, TUV, ISO9001
  • Product Origin :       Jiangsu Province, China
  • Product Warranty : 12 months standard warranty
  • Telephone Us :        0086-514-87892928



Get Your FREE no-obligation Quote Add to Inquiry Cart
  • Detailes
  • Optional Accessory
  • FAQ
  • Download
Detailes

MM-BF30Vario Drilling Milling Machine



Such kind of MM-BF30 Vario is the high precision stable metal drilling milling machine which is been made in ISO9001 factory from MAXNOVO MACHINE with CE Safety Certification. It is the approved classic gear drive stable drilling milling machine with bigger drilling capacity to uses even bigger spindle taper, the longer working table, more powerful driving motor and it is complete equipped with two digital display to show speed and spindle stroke. In additional, this milling machine features step-less speed adjustment as well as a tilt-able mill head at ±90 degree. The optional 2-axis digital position indicator is for demanding users.







Main  Feature :

Convincing Arguments : Quality, Efficiency and Price

-  Max. Drilling Capacity is Ø 30 mm

-  Large range of applications such as groove milling, face milling, tapping and many more

-  EMC filter (to protect sensitive electronics for override mains-borne signals class B)

-  All guide-ways are ground and sight scrapped (oil pockets for greasing)

-  Precisely manufactured

-  Digital speed and spindle stroke indicator included

-  Two-row angular contact bearings in the axis, can be adjusted free of play

-  Bellow as guide protection

-  Right-hand / Left- hand rotation

-  2-step gear unit for optimal power transmission

-  Serially equipped with left and right turning ideal for thread cutting

-  Direct current motor for ideal torque at lower speed

-  Dovetail guiding for the X-axis, Y-axis and Z-axis, adjustable via gibs

-  High-quality bearings guarantee high spindle concentricity ( less than 0.015mm)

-  Mill head tilt-able to both sides for angular boring, milling of bevels etc

-  Handle for spindle adjustment, hand-wheel for fine feed

-  EMC filter (to protect sensitive electronics for override mains-borne signals)

-  Drilling milling head tilt-able by ± 90 for milling and drilling works at different angles

-  Height-adjustable protective screen with micro switch providing maximum protection of

   the user against chips and parts flying off at high speed

-  Connecting voltage is Single Phase 230V or 110V

-  Certificate of Original (CO, FORM A, FORM E, FORM F )















Technical  Data :



Product  Name:

Variable Speed High Precision Drilling Milling Machine

Product  Item:

MM-BF30 Vario

MM-BF30L Vario

Drilling-Milling Capacity



Max. Drilling Capacity :

Ø 30 mm

Ø 30 mm

Max. Face Milling Capacity :

Ø 75 mm

Ø 75 mm

Max. End  Milling Capacity :

Ø 30 mm

Ø 30 mm

Spindle  Seat



Spindle  Stroke :

70 mm

70 mm

Spindle  Taper :

MT 3 / M12

MT 3 / M12

Throat  (Working  Range) :

185 mm

185 mm

Drilling-milling head



Swivel  Range :

±90°

±90°

Spindle  Speeds :

50—3000 RPM

50—3000 RPM

Gear  Speeds :

2 steps, electrically adjustable speed

Cross table





Table Length :

730 mm

840 mm

Table Width :

210 mm

210 mm

T-Slot  size / distance :

14 mm / 63 mm

14 mm / 63 mm

T-Slot Number :

3 Pieces

3 Pieces

Load of cross table max. :

80 KGS

80 KGS

Travels





Travel  X-Axis :

500 mm

570 mm

Travel  Y-Axis :

220 mm

220 mm

Travel  Z-Axis :

360 mm

360 mm

Electrical connection





Connecting Voltage :

Single Phase 230V or 110V

Connecting Frequency :

50HZ or 60HZ

Motor Power :

1100W  Powerful Motor

Net Weight :

215 KGS

235 KGS

Gross Weight :

230 KGS

250 KGS

Packing Size :

890 X 710 X 1150 mm

900 X 850 X 1200 mm

Packing Type :

Export Type Wooden Case

Standard Accessory :

Digital Speed Readout, Morse Taper, Drill Chuck,

Halogen Lamp, Draw-in Rod, Tools and Toolbox









Optional Accessory

In order to convenient customers, our MAXNOVO MACHINE factory offers the ORIGINAL high quality special optional spare parts of these metalworking machines in the bellowing PDF document for you to choose. All these special optional spare parts could be delivery to you with your purchased machines together so as to save your transportation cost and save your time.












FAQ

Frequently Asked Questions :


(1). QUESTION : Are you a manufacturer factory or trading company ?
ANSWER : We are the SGS On-site Recognized OEM / ODM China manufacturer factory to produce Lathe Machine, Milling Machine, Drilling Machine, CNC Machine and Cutting Machine with export license. we have an experienced team made up of "A" player who have a passion for doing everything great to create more value for customers world-wide.



(2). QUESTION : Why choose cooperate with your company ?
ANSWER :  -Right people, Right product, Right price

                  -Company-wide customer awareness
                  -Reliable Quality and All components from world leading suppliers
                  -Cost-effective export infrastructure and total supply chain management




(3). QUESTION : Where is your factory located ?  How can I visit there ?
ANSWER : Our ISO90001 certified manufacturer factory located in Yangzhou city, Jiangsu Province, P.R. China. It takes about 2 hours from SHANGHAI city by train. Warmly welcome all clients to visit us at your convenient time.



(4). QUESTION : Can you do OEM ?
ANSWER : Yes, we have the good technical ability to do OEM / ODM to meet clients' special requirements. The technical department has a well-established team of technically highly qualified specialists. These well-founded expertise and technical department allows flexible and creative implementation of all requirements which are demanded for our products and service. The dynamic technical team of specialists comprises engineers, executives who had solid working experience in the field of offering one-stop complete solution for high precision machines.




(5). QUESTION : How does your factory do regarding quality control ?
ANSWER : Offering the trustable quality is our dignity and all our teammates insist on doing it accurate at the first time. At MAXNOVO MACHINE, We see the basis for a constantly high customers’ satisfaction and our current and future market success in the clear Quality Control orientation of all employees. Beside delivery reliability and service the quality of products is of highest importance for you. The quality control is ensured by continuous internal and external monitoring on site by these well-trained and motivated quality managers. The comprehensive inspection for Incoming goods Quality Control (IQC) and Outgoing goods Quality Control (OQC) is performed according to the technical guidelines strictly.









(6). QUESTION : What is the average delivery time ?
ANSWER : Normally, it would be within 1 – 2 weeks since our financial department confirm receive customers' contract payment. For mass production purchase order at big quantity, the delivery time could be discussed with us case by case.






(7). QUESTION : What is the product warranty ?

ANSWER : The standard product warranty would be 12 months.







(8). QUESTION : What does your company care ?

ANSWER : As a responsible manufacturer of metalworking machines and CNC working machines, we care about the working conditions and social welfare of our employees. We care about the quality and source of the material components. We care about how to make our machines still work well for you even after years of operation. We care about whether our machines have supported clients to increase their product sales and enhance brand image.










Download
Name
Size
Download
BF30Vario-Drilling-Milling-Machine-MAXNOVO.pdf
335.69KB
